115 VAC diaphragm vacuum pump designed for maple sap collection systems. Built with FDA-approved materials for all wetted components and suitable for use with 1-1/4" to 2" hose sizes. This pump can support up to 400 taps on well-managed sugarbush lines and can achieve up to 28 in Hg vacuum depending on system setup.
Features:
-
FDA-approved materials for all components in contact with sap
-
Supports up to 400 taps on well-managed lines
-
Up to 28 in Hg vacuum
-
8.3 GPM / 1.1 CFM capacity
-
Efficient 120 watt, 115 VAC induction motor
-
See-Thru pump guard for easier diaphragm inspection
-
No releaser required
-
Runs wet or dry
-
Accommodates 1-1/4" Tapped Female Inlet/Outlet
-
Ships with spare diaphragm
Performance:
-
Max Pressure: 10 psi
-
Lift/Head: 20–23 ft
-
Capacity: 9.9 GPM
- Volume per Stroke: 0.55 qt
-
Max Service Temp: 220°F
